Manufacturer

Fortinet

Categories

Fortinet Electronics

MPN

FTNFS124EPOE

Model#

FS124EPOE

UNSPSC Code

2

Information

Product Description: Fortinet FortiSwitch 124E-POE - switch - 24 ports - managed - rack-mountable
Device Type: Switch - 24 ports - managed
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 4 x Gigabit SFP + 12 x 10/100/1000 (PoE)
Power Over Ethernet (PoE): PoE
PoE Budget: 185 W
Performance: Switching capacity: 56 Gbps  ¦ Packets per second: 41.66 Mpps  ¦ Latency: 4 ms
Capacity: VLANs supported: 4000 Â ¦ Link aggregation groups: 8 Â ¦ Total link aggregation groups: 8
MAC Address Table Size: 8K entries
Jumbo Frame Support: Yes
Remote Management Protocol: SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI
Features: Flow control, auto-negotiation, port mirroring, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Jumbo Frames support, STP Root Guard, fanless, Link Aggregation Control Protocol (LACP), DHCP client, Management Information Base (MIB), 512KB packet buffer, 802.1x authentication, Storm Control, Back Pressure Support, Link Aggregation, Management Information Base (MIB) II, Guest VLAN, STP BPDU Guard, IPv6 management, VLAN Tagging, FortiLink Mode, MAC Access Bypass (MAB), Telnet server
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3at, IEEE 802.1AX
Power: AC 120/230 V (50 - 60 Hz)
Dimensions (WxDxH): 17.3 in x 12.2 in x 1.7 in
Weight: 11.09 lbs
Manufacturer Warranty: Limited lifetime warranty
Device Type: Switch - 24 ports - managed
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 4 x Gigabit SFP + 12 x 10/100/1000 (PoE)
Power Over Ethernet (PoE): PoE
PoE Budget: 185 W
Performance: Switching capacity: 56 Gbps  ¦ Packets per second: 41.66 Mpps  ¦ Latency: 4 ms
Capacity: VLANs supported: 4000 Â ¦ Link aggregation groups: 8 Â ¦ Total link aggregation groups: 8
MAC Address Table Size: 8K entries
Jumbo Frame Support: Yes
Remote Management Protocol: SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI
Features: Flow control, auto-negotiation, port mirroring, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Jumbo Frames support, STP Root Guard, fanless, Link Aggregation Control Protocol (LACP), DHCP client, Management Information Base (MIB), 512KB packet buffer, 802.1x authentication, Storm Control, Back Pressure Support, Link Aggregation, Management Information Base (MIB) II, Guest VLAN, STP BPDU Guard, IPv6 management, VLAN Tagging, FortiLink Mode, MAC Access Bypass (MAB), Telnet server
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3at, IEEE 802.1AX
RAM: 256 MB DDR3 SDRAM
Flash Memory: 32 MB
Interfaces: 24 x 1000Base-T RJ-45  ¦ 4 x Gigabit LAN SFP  ¦ 1 x console RJ-45 management  ¦ 12 x 1000Base-T RJ-45 PoE
Power Device: Internal power supply
Voltage Required: AC 120/230 V (50 - 60 Hz)
Power Consumption Operational: 17.78 Watt
MTBF: >10 years
Compliant Standards: UL, VCCI, BSMI, CB, FCC, RoHS2, RCM
Width: 17.3 in
Depth: 12.2 in
Height: 1.7 in
Weight: 11.09 lbs
Service & Support: Limited warranty - lifetime
Min Operating Temperature: 32 Â °F
Max Operating Temperature: 104 Â °F
Humidity Range Operating: 10 - 90% (non-condensing)
Min Storage Temperature: -40 Â °F
Max Storage Temperature: 158 Â °F
COO: TAIWAN
TAA compliance: Yes

Unit of Measure

Item Weight

12

Ships via UPS

Y

Brand

Fortinet

Manufacturer Stock No.

FS-124E-POE
