Manufacturer

SIIG

Categories

SIIG Electronics

MPN

SIGLBGE0611S1

Model#

LBGE0611S1

UPC Code

662774043982

UNSPSC Code

2

Information

Product Type: PCIe Card
Form Factor: N/A
Network / Interface Type: PCI Express 2.1
Networking / Ports Qty: 1
Data Transfer Rate: 10 Mbps; 100 Mbps
Data Link Protocol: IEEE 802.3; IEEE 802.3u; IEEE 802.3az
Connectivity Technology: Wired
Transport Protocol: Gigabit Ethernet
Interfaces & Connections: 2x 8-Pin, RJ-45, Female
Width: 3.5
Inch
Depth: 4.72 Inch
Height: 0.83 Inch
PC Compatibility: Win
Service & Support Type: 1 Year Limited Warranty
Features: Easily add a multi-Gigabit Ethernet port through an available x1 PCIe slot to server and desktop computers
Compliant with PCI Express Specification Revision 2.1
Compatible with NBASE-TTM Alliance PHY Specification
Supports 4 Multi-Speed of 10M/100M/1Gbps/2.5Gbps Ethernet data rates
Compatible with IEEE 802.3, 802.3u, 802.3a, IEEE 802.3bz (2.5GBase-T), IEEE 802.1Q VLAN tagging, IEEE 802.3az (Energy Efficient Ethernet)
Supports jumbo frame to 16K bytes for higher and better data throughput
Supports Full Duplex flow control IEEE 802.3x
Supports Wake-On-LAN and RealWoW! Technology (Remote wake-up)
Fits both standard and low profile system chassis with the included spare low profile bracket

Unit of Measure

Item Weight

0.09

Ships via UPS

Y

GTIN Item

662774043982

UPC Retail

662774043982

Brand

SIIG

Manufacturer Stock No.

LBGE0611S1
